Equipment used to send written documents over a telephone network.

See facsimile (fax) machine in : french | spanish

Button used to automatically dial a fax number held in memory.

The buttons used to carry out various operations such as automatic dialing, batch transmission and store-and-forward transmission.

Button used to cancel an operation or a setting.

The buttons used to select an option or adjust parameters such as transmission mode and contrast.

Movable device that adjusts the position of the original documents from side to side.

Slot into which outgoing faxes are inserted; it converts graphic data into electric pulses for transmission.

Tray in which incoming faxes are collected.

Liquid crystal display that shows a variety of information such as dialed number, sender’s number, equipment settings and completed operations.

Tray in which original documents are collected once they have been scanned by the fax machine.
